Jinko Tiger Neo 610W Solar Panel

The Jinko Tiger Neo 610W Solar Panel is a high-performance monocrystalline panel, offering an efficiency of around 21.6%. With a power output of 610 watts, it features a robust design and durable materials, making it ideal for residential and commercial solar installations. Its advanced technology ensures reliable energy generation and longevity.

General Specifications:

• Model: Jinko Tiger Neo 610W
• Type: Monocrystalline
• Power Output: 610 Watts
• Efficiency: Approximately 21.6%
• Dimensions: About 2024 mm x 1134 mm x 30 mm
• Weight: Approximately 27 kg

Electrical Specifications:

• Open Circuit Voltage (Voc): 49.6 V
• Short Circuit Current (Isc): 13.26 A
• Maximum Power Voltage (Vmp): 41.2 V
• Maximum Power Current (Imp): 14.81 A

Performance Characteristics:

• Temperature Coefficient (Pmax):  -0.34%/°C
• Temperature Coefficient (Voc):  -0.26%/°C
• Temperature Coefficient (Isc): +0.05%/°C

Design and Durability:

• Frame Material: Anodized aluminum alloy
• Glass Type: High-transmittance tempered glass
• IP Rating: IP68 (water and dust resistant)
• Warranty: 1 Year Warranty

Applications:

• Suitable for residential, commercial, and utility-scale solar power systems.
