Dell PowerEdge R350 1U Rack Server Xeon E-2314 16GB RAM 2TB HDD

The Dell PowerEdge R350 1U Rack Server Spec-sheet is designed for small-to-medium businesses. Powered by an Intel Xeon E-2314 processor, it offers 16 GB of ECC DDR4 memory and 2TB of storage (expandable). With dual 1GbE network ports, flexible PCIe expansion slots, and remote management via iDRAC9, it delivers efficient performance for tasks like virtualization and cloud services in a cost-effective, energy-efficient design. Ideal for businesses requiring a reliable, compact server for various workloads.

Specification for the Dell PowerEdge R350 Xeon E-2314 16GB RAM 2TB HDD 1U Rack Server (PER350SPL2):

---

Dell PowerEdge R350 – 1U Rack Server

Model: PER350SPL2

---

Key Specifications:

Processor:

• Model: Intel Xeon E-2314
• Cores: 4 cores, 8 threads
• Base Clock Speed: 3.0 GHz
• Turbo Boost: Up to 4.4 GHz
• Cache: 12 MB Intel Smart Cache
• Socket: LGA 1200
• TDP: 80W

Memory:

• Installed Memory: 16 GB (1 x 16GB DDR4)
• Maximum Memory: 64 GB (4 x 16GB DDR4)
• Memory Type: DDR4 ECC (Error-Correcting Code)
• Memory Speed: 2933 MT/s

Storage:

• Hard Drive: 2TB 3.5″ HDD (SATA)
• RAID: Software RAID (Optional hardware RAID controller)
• Storage Bays: 1 x 3.5″ bay (supports additional drives)
• Max Internal Storage: 2TB (expandable with additional drives)

Networking:

• NIC: 2 x 1GbE (Gigabit Ethernet)
• Optional Network Cards: Available with different speeds (10GbE or higher)

Expansion Slots:

• PCIe Slots:
  • 1 x PCIe 3.0 x16 slot (for additional expansions such as network cards, RAID controllers)
  • 1 x PCIe 3.0 x8 slot (for optional expansions)

Power Supply:

• Power Supply Type: 1 x 550W (Redundant PSU option available)
• Power Efficiency: 80 PLUS Platinum certified (for energy efficiency)

Physical Dimensions:

• Form Factor: 1U Rack Server
• Height: 1.7 inches (43.6 mm)
• Width: 17.1 inches (434.0 mm)
• Depth: 26.5 inches (673.3 mm)
• Weight: Approx. 22 lbs (10 kg)

Cooling:

• Fans: Hot-plug fans for optimal airflow
• Thermal Management: Advanced thermal design to ensure cooling efficiency in dense environments

Management & Monitoring:

• Dell OpenManage: Dell’s management suite for monitoring and automation
• iDRAC9: Remote management with integrated Dell Remote Access Controller (iDRAC9) for out-of-band management, system monitoring, and firmware updates.

Operating System Support:

• Supported Operating Systems:
  • Windows Server 2019/2022
  • Red Hat Enterprise Linux
  • Ubuntu Server
  • VMware ESXi (for virtualization)

Security Features:

• Trusted Platform Module (TPM): TPM 2.0 for secure boot and data protection
• Security Lock: Physical lock slot for enhanced security

---

Optional Upgrades and Add-ons:

• Additional memory (up to 64 GB)
• SSD storage options for higher performance
• RAID controller for hardware RAID support
• Additional network cards (10GbE, fiber channel)
• Backup power supply (UPS)

---

Use Cases:

• Virtualization hosts
• Small-to-medium business server environments
• Cloud-based applications and services
• Database management systems
• File and print sharing
• Remote office or branch office solutions
