HPE Proliant DL360 Gen11 Intel Xeon Gold 5416S 32GB Server

Theis  HPE ProLiant DL360 Gen11 Intel Xeon Gold 5416S a powerful, compact 1U rack server designed for demanding workloads, virtualization, and data center environments. Equipped with an Intel Xeon Gold 5416S processor, 32 GB of DDR5 memory (expandable to 6 TB), and flexible storage options, it supports high-performance computing with advanced management and security features, including HPE iLO 6 and Silicon Root of Trust. Ideal for businesses seeking a scalable, reliable server solution with high efficiency in a small form factor.

General Information

• Model: HPE ProLiant DL360 Gen11
• Form Factor: 1U Rack Mountable Server
• Purpose: High-performance, enterprise-grade server for data-intensive workloads, cloud environments, virtualization, and HPC (High-Performance Computing)

Processor (CPU)

• CPU Type: Intel Xeon Scalable Processor (4th Generation)
• Processor Model: Intel Xeon Gold 5416S
• Cores / Threads: 16 Cores / 32 Threads
• Base Frequency: 2.10 GHz
• Max Turbo Frequency: Up to 3.30 GHz
• Cache: 30 MB L3 Cache
• TDP (Thermal Design Power): 165W
• Scalability: Supports up to 2 processors (1 installed, 1 available slot)

Memory (RAM)

• Installed Memory: 32 GB DDR5 ECC Registered
• Memory Type: DDR5 4800 MT/s RDIMM (Registered DIMM)
• Max Memory Capacity: Up to 6 TB (with 256 GB DDR5 RDIMMs or 512 GB LRDIMMs across 32 DIMM slots)
• Memory Slots: 32 DIMM slots (16 per processor)

Storage

• Storage Controller: HPE Smart Array S100i SR Gen11 Software RAID (RAID 0, 1, 5, 10)
• Drive Bays:
  • Supports up to 8x SFF (Small Form Factor) hot-swappable drive bays
  • Alternatively, supports up to 4x LFF (Large Form Factor) drives
• Drive Options: NVMe, SAS, SATA SSDs, and HDDs
• Included Storage: Storage drives typically sold separately; configurations vary based on user needs

Expansion Slots

• PCIe Slots: Up to 3 PCIe Gen5 slots (dependent on riser and configuration)
• Network Interface:
  • HPE Ethernet 1Gb 4-port or 10Gb 2-port adapters (options for additional NICs available)

Power Supply

• Power Supply Options:
  • Dual redundant hot-plug power supplies (standard or high-efficiency options)
• Wattage Options: 500W, 800W, or 1600W (depending on configuration)

Management and Security

• Integrated Management: HPE Integrated Lights-Out 6 (iLO 6) Advanced Management (remote management, configuration, and monitoring)
• Security Features:
  • Silicon Root of Trust
  • Secure Boot and Secure Recovery
  • HPE iLO Security Dashboard
  • Optional TPM (Trusted Platform Module) 2.0
  • Optional HPE Secure Encryption for data protection

Operating System Support

• Supported Operating Systems:
  • Windows Server
  • VMware vSphere
  • Red Hat Enterprise Linux (RHEL)
  • SUSE Linux Enterprise Server (SLES)
  • Ubuntu
  • Other OS options via compatibility (check HPE support for detailed list)

Networking

• Standard Networking: 1Gb Ethernet or 10Gb Ethernet options
• Additional Networking:
  • Option to add fiber or Ethernet NICs for enhanced connectivity
  • Support for high-speed interconnects such as InfiniBand or Omni-Path

Cooling

• Cooling System: High-efficiency, redundant fans (configurable for increased redundancy and improved cooling)

Warranty and Support

• Warranty: Standard 3-year parts, 3-year labor, 3-year onsite support
• Additional Support Options: HPE Foundation Care, Proactive Care, and Datacenter Care (available for added support)
