HPE Networking Instant On AP11 Access Point

The HPE Networking Instant On AP11 is a versatile indoor access point designed for small to medium-sized businesses. Offering dual-band Wi-Fi with speeds up to 1.3 Gbps, it supports 802.11a/b/g/n/ac standards and features 2×2 MIMO technology for enhanced performance. The AP11 is easy to manage via the HPE Instant On mobile app and web portal, making it an ideal solution for reliable wireless connectivity in diverse environments.

General Specifications

• Model: HPE Instant On AP11
• Type: Indoor Access Point
• Deployment: Ceiling-mounted or wall-mounted

Hardware Specifications

• Dimensions: 7.9 in x 7.9 in x 1.8 in (200 mm x 200 mm x 45 mm)
• Weight: Approximately 1.1 lbs (0.5 kg)
• Power Supply: PoE (Power over Ethernet) 802.3af or AC power adapter
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Humidity: 10% to 90% (non-condensing)

Wireless Specifications

• Wireless Standards: IEEE 802.11a/b/g/n/ac
• Frequency Bands: Dual-band (2.4 GHz and 5 GHz)
• Max Data Rate: Up to 1.3 Gbps (combined)
• MIMO Technology: 2×2 MIMO
• Transmit Power: Adjustable
• Channel Width: 20/40/80 MHz

Networking Features

• Ethernet Ports: 1 x 10/100/1000 Mbps
• Management: HPE Instant On mobile app and web portal
• VLAN Support: Yes
• Security Features: WPA3, WPA2, 802.1X, MAC address filtering

Additional Features

• User Capacity: Supports up to 100 users concurrently
• Quality of Service (QoS): Enhanced for voice and video traffic
• Mesh Networking: Supports wireless mesh networking
• Smart Antenna: Integrated for improved coverage

Compliance and Certifications

• Certifications: CE, FCC, RoHS

The HPE Networking Instant On AP11 Access Point is suitable for a variety of applications, including:

1. Small to Medium-Sized Businesses: Provides reliable Wi-Fi coverage for offices, retail stores, and service areas.
2. Education: Ideal for classrooms and educational institutions, supporting online learning and administrative tasks.
3. Healthcare: Facilitates secure wireless access for medical devices and staff in hospitals and clinics.
4. Hospitality: Enhances guest experiences in hotels, cafes, and restaurants with seamless connectivity.
5. Public Spaces: Supports connectivity in libraries, community centers, and parks, offering internet access to visitors.
6. Home Offices: A great choice for remote workers needing stable and fast internet for productivity.
