HPE Proliant DL20 Gen11 16GB RAM-U 4SFF 500W PS Server

The HPE Proliant DL20 Gen11 16GB RAM-U 4SFF 500W PS Server is a compact 1U rack server designed for small to medium businesses. Powered by an Intel Xeon E-2434 processor, it delivers reliable performance with 16GB DDR4 memory, upgradable to 128GB. With 4 SFF drive bays, dual-port 1GbE networking, and HPE iLO 6 for remote management, it provides a cost-effective, scalable solution for diverse workloads in space-constrained environments.

HPE ProLiant DL20 Gen11 E-2434 Server (P65395-421):

---

Product Overview

The HPE ProLiant DL20 Gen11 is a compact and versatile rack server designed for small to medium businesses and enterprise environments needing a cost-effective, space-saving solution. Powered by Intel’s latest processor technology, it offers reliability and scalable performance for a range of IT workloads.

---

Specifications

Model and Part Number

• Model: HPE ProLiant DL20 Gen11
• Part Number: P65395-421

Processor

• CPU Model: Intel Xeon E-2434
• Base Clock Speed: 3.4 GHz
• Cores: 4 Cores / 8 Threads
• Cache: 8 MB L3 Cache
• Socket: LGA 1200
• Max Turbo Frequency: Up to 4.5 GHz

Memory

• Installed Memory: 16GB DDR4
• Memory Type: DDR4-3200 MHz Unbuffered (UDIMM)
• Maximum Capacity: Up to 128GB
• Memory Slots: 4 DIMM slots
• ECC Support: Yes

Storage

• Drive Bays: 4 x Small Form Factor (SFF) Bays
• Drive Compatibility: SAS, SATA, and NVMe options
• RAID Support:
  • HPE Smart Array E208i-a SR Gen10 Controller
  • Supports RAID levels 0, 1, 5, and 10
• Default Configuration: No drives included, user-configurable

Network

• Integrated Network Interface: Dual-Port HPE Ethernet 1Gb 332i Adapter
• Expansion Options: 1 PCIe 3.0 slot for additional network adapters or storage controllers

Power Supply

• Power Supply Rating: 500W
• Type: HPE Flexible Slot Power Supply
• Efficiency: 80 PLUS Platinum-certified

Management and Security

• Management: HPE iLO 6 (Integrated Lights-Out) with HPE iLO Advanced and Essentials licenses for remote management
• Security Features:
  • HPE Silicon Root of Trust for firmware protection
  • Secure Boot
  • Optional TPM (Trusted Platform Module)

Form Factor

• Chassis: 1U Rack-mountable
• Dimensions: 1.69 x 17.11 x 15.05 inches (4.3 x 43.5 x 38.2 cm)
• Weight: Approx. 12.9 kg (28.4 lbs)

Operating System Compatibility

• Supported OS:
  • Windows Server 2019 and 2022
  • Various Linux distributions (RHEL, Ubuntu, SUSE)
  • VMware ESXi (various versions)

Expansion Slots and Ports

• PCIe Slots: 1 x PCIe 4.0 slot (x16)
• USB Ports:
  • 2 x USB 3.0 (rear)
  • 2 x USB 3.0 (front)
  • 1 x USB 3.0 (internal)
• Other Ports:
  • 1 VGA port
  • Serial and video ports for console access

---

Additional Features

• Cooling: Multiple fans with advanced cooling design
• Environmental Operating Ranges:
  • Temperature: 10°C to 35°C (50°F to 95°F)
  • Humidity: 8% to 90% non-condensing
