Ubiquiti UISP airMAX AC PrismStation 5GHz 30° Horn Antenna

The Ubiquiti UISP airMAX AC PrismStation 5GHz with 30° Horn Antenna is a high-performance, narrow-beam antenna system designed for targeted, interference-resistant point-to-multipoint (PtMP) wireless deployments. Engineered for use in dense radio environments, the 30° horn provides precise beam control and enhanced isolation, reducing co-channel interference and improving overall network performance. Featuring 16 dBi gain, dual-linear polarization, and a modular design, it integrates seamlessly with Ubiquiti radios such as the PrismStation and IsoStation. This antenna is ideal for long-distance or high-density sectors where narrow coverage and signal clarity are essential. Its weather-resistant build and support for UISP platform management make it a reliable solution for ISPs and wireless network professionals seeking scalable, directional connectivity.

📡 Wireless & RF Specifications

• Frequency Range: 5.15 – 5.85 GHz

• Gain: 19 dBi

• Beamwidth:

  • Horizontal (HPOL): 30°

  • Vertical (VPOL): 30°

  • Elevation: 30°

• Polarization: Dual-Linear

• Cross-Polar Isolation: 17 dB

• Maximum VSWR: 1.7:1

🧱 Mechanical & Environmental

• Dimensions: Ø 221.4 × 184.2 mm (8.71 × 7.3″)

• Weight: 1.1 kg (2.4 lb)

• Wind Survivability: 200 km/h (125 mph)

• Wind Loading: 56 N at 200 km/h (12.6 lbf at 125 mph)

🔌 Compatibility

• Compatible Radios:

  • IsoStation IS-M5

  • IsoStation IS-5AC

  • PrismStation PS-5AC

  • airFiber AF-LTU

This antenna is ideal for medium-density deployments, offering enhanced co-location performance and reduced interference. Its modular design allows for easy integration with compatible Ubiquiti radios, making it a versatile choice for wireless network operators seeking efficient and scalable solutions
