Ubiquiti UniFi AC Wave 2 AP with Security Radio

The Ubiquiti UniFi AC Wave 2 Access Point with Security Radio offers high-performance dual-band Wi-Fi with speeds up to 3.1 Gbps (600 Mbps on 2.4 GHz, 2,533 Mbps on 5 GHz) using 4×4 MU-MIMO. It features a dedicated security radio to detect and mitigate interference, enhancing network protection. Ideal for high-density environments, it supports PoE+ for easy installation and is managed via the UniFi Controller, making it perfect for businesses and campuses with high security and performance needs.

General Specifications:

• Model: UniFi AC Wave 2 with Security Radio (UAP-AC-SHD)
• Dimensions: 213 x 213 x 51 mm
• Weight: 657 g
• Mounting: Ceiling or wall mount (mounting hardware included)

Wi-Fi Performance:

• Wi-Fi Standards:

  • 802.11a/b/g/n/ac (Wi-Fi 5, Wave 2)
  • Wi-Fi 6 (802.11ax) support in future firmware or hardware revisions

• Dual-Band:

  • 2.4 GHz: 600 Mbps (4×4 MU-MIMO)
  • 5 GHz: 2,533 Mbps (4×4 MU-MIMO)
  • Total Throughput: Up to 3.1 Gbps (combined 2.4 GHz + 5 GHz)

• Security Radio:

  • Dedicated security radio for enhanced network protection
  • Detects and mitigates interference, enabling secure and efficient Wi-Fi operations
  • Real-time monitoring of nearby radio spectrum

• Antennas:

  • 2.4 GHz: 4 x 6 dBi internal antennas
  • 5 GHz: 4 x 6 dBi internal antennas

• Wi-Fi Features:

  • MU-MIMO (Multi-User, Multiple Input, Multiple Output): Allows simultaneous communication with multiple devices for increased throughput.
  • Beamforming: Enhances range and performance by focusing the Wi-Fi signal toward client devices.
  • Band Steering: Automatically moves devices to the less congested 5 GHz band for optimal performance.
  • Airtime Fairness: Distributes network access evenly among devices to prevent congestion.

Networking:

• Ports:
  • 2 x Gigabit Ethernet Ports (1 for PoE In, 1 for LAN)
  • PoE (Power over Ethernet): 802.3at PoE+ (powered via Ethernet cable)
• Networking Features:
  • Supports DHCP, Static IP, DNS, and VLAN
  • 802.1Q VLAN tagging for network segmentation
  • Quality of Service (QoS) for traffic prioritization

Power:

• Power Consumption:

  • 12W (typical)
  • Max power consumption: 25W

• Power Options:

  • 802.3at PoE+ (PoE injector or switch required, sold separately)

Environmental Specifications:

• Operating Temperature: -20°C to 70°C (-4°F to 158°F)
• Operating Humidity: 5% to 95% non-condensing

Certifications:

• Safety Standards: UL, CE, FCC, IC
• Environmental Standards: RoHS Compliant

Key Features:

• Wi-Fi 5 Wave 2 Performance: Provides up to 3.1 Gbps total throughput with 4×4 MU-MIMO technology for both 2.4 GHz and 5 GHz bands, ideal for high-density environments.
• Dedicated Security Radio: A dedicated security radio helps protect the network by identifying and mitigating interference in real-time, improving overall performance and security.
• Advanced Wi-Fi Management: Managed via UniFi Network Controller, with features like guest portals, detailed analytics, and enhanced security settings.
• PoE+ Support: Simplifies installation by using PoE to deliver both power and data over a single Ethernet cable.
• High Capacity: Designed for environments with many connected devices, offering robust performance in high-density areas.

Use Cases:

• Ideal for businesses, campuses, and high-density indoor environments that require robust, secure, and high-performance wireless coverage.
• Suitable for environments with demanding security requirements, leveraging the dedicated security radio for optimal network protection.
