Ubiquiti UniFi Express WiFi 6 Cloud Gateway

The Ubiquiti UniFi Express is a compact, all-in-one WiFi 6 cloud gateway and access point, ideal for home offices, small businesses, or remote deployments. Combining a powerful dual-band WiFi 6 access point with integrated gateway and cloud management, UniFi Express delivers fast, secure wireless coverage and centralized control via the UniFi Network platform. It features a 2.5 GbE WAN/LAN port and built-in Bluetooth for easy setup, while offering advanced UniFi features like traffic monitoring, VLAN support, VPN, and firewall configuration—making it a simple yet powerful solution for modern network needs.

🧠 Hardware & Physical

• Processor: Quad-Core ARM Cortex-A53 at 1.5 GHz

• Memory: 2 GB DDR4 RAM

• Networking Ports:

  • (1) Gigabit Ethernet (GbE) WAN port

  • (1) Gigabit Ethernet (GbE) LAN port

• Management Interfaces: Ethernet, Bluetooth

• Power Input: USB Type-C (5V DC/3A)

• Max Power Consumption: 10W

• Dimensions: 98 x 98 x 30 mm (3.6 x 3.6 x 1.2 inches)

• Weight: 302 g (10.7 oz)

• Enclosure Material: Polycarbonate

• Operating Temperature: -10°C to 45°C (14°F to 113°F)

• Operating Humidity: 5% to 95% non-condensing

• Certifications: CE, FCC, IC

📶 Wireless (WiFi 6)

• Standards Supported: 802.11a/b/g/n/ac/ax

• MIMO Configuration:

  • 2.4 GHz: 2×2 (Downlink/Uplink MU-MIMO)

  • 5 GHz: 2×2 (Downlink/Uplink MU-MIMO)

• Max TX Power:

  • 2.4 GHz: 22 dBm

  • 5 GHz: 25 dBm

• Antenna Gain:

  • 2.4 GHz: 4 dBi

  • 5 GHz: 5.15 dBi

• Throughput Rates:

  • 2.4 GHz: Up to 573.5 Mbps

  • 5 GHz: Up to 2.4 Gbps

• Antennas:

  • (2) Internal dual-band WiFi antennas (2.4 GHz / 5 GHz)

  • (1) Internal single-band Bluetooth antenna

• BSSID Support:

  • Console Mode: 3 per band

  • Standard AP Mode: 8 per band

• Zero Wait DFS: Yes

• Concurrent Clients: 60+

🔐 Networking & Security

• VLAN Support: 802.1Q

• Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

• Advanced QoS: Per-user rate limiting

• Guest Traffic Isolation: Supported

• Firewall:

  • Full stateful firewall

  • Application-aware firewall rules

  • Content, country, domain, and ad filtering

• SD-WAN: License-free

• VPN Support:

  • WireGuard

  • L2TP

  • OpenVPN server and client

  • IPsec site-to-site VPN

  • One-click Teleport VPN

• Policy-based WAN and VPN Routing: Yes

• DHCP:

  • Customizable DHCP server

  • DHCP relay

• IGMP Proxy: Yes

• IPv6 ISP Support: Yes

• Internet Quality and Outage Reporting: Yes

📊 Software & Management

• Management Interface: UniFi Network App (iOS™ and Android™)

• Application Requirements: UniFi Network version 8.0.7 and later

• Display: 0.96″ LCM status display

• Factory Reset Button: Yes
