Ubiquiti UniFi 8 x 10G SFP+ Ports Aggregation Switch

The Ubiquiti UniFi Aggregation Switch with 8 x 10G SFP+ ports is a high-performance Layer 2 switch designed to deliver ultra-fast, low-latency connectivity for enterprise networks and high-bandwidth environments. Ideal for network aggregation, it provides a compact, fanless design that operates silently, making it suitable for offices, studios, or rack deployments. With full 10-Gigabit throughput across all ports, seamless integration with the UniFi Controller software, and robust performance, the switch is perfect for linking UniFi access points, switches, and servers while maintaining centralized management and monitoring. Its reliability, scalability, and efficiency make it a key component in modern high-speed network infrastructures.

Full Features

• Ports: 8 x 10G SFP+

• Switching Capacity: 160 Gbps

• Forwarding Rate: 119.04 Mpps

• Throughput: 80 Gbps (non-blocking)

• Management Interface: UniFi Network Controller (in-band Ethernet)

• Display: 1.3″ color touchscreen with AR switch management

• Rackmount: 1U form factor, 4.7″ (120 mm) depth

• Cooling: Fanless design

• Power Consumption: 30W max

• Power Input: 100–240V AC, 50/60 Hz

• Operating Temperature: -5 to 40°C

• Operating Humidity: 10–90% (non-condensing)

• Certifications: CE, FCC, IC

• Weight: 2.65 kg (5.84 lb) without mount

• Dimensions: 442.4 x 120 x 43.7 mm

• Enclosure: SGCC steel

Applications

1. Data Centers & Server Rooms

   • Aggregates multiple high-speed connections between core switches, servers, and storage systems.

2. Enterprise Networks

   • Ideal for unifying backbone infrastructure across multiple floors or buildings with high-throughput demands.

3. Campus & Educational Institutions

   • Connects multiple network segments across campuses to ensure seamless and high-speed data flow between departments.

4. Broadcasting & Media Production

   • Supports large file transfers, video editing workflows, and media servers with ultra-fast 10G links.

5. ISP & MSP Environments

   • Works as a distribution switch in ISP core networks or managed service provider deployments.

6. High-Density Wi-Fi Networks

   • Aggregates traffic from multiple UniFi Wi-Fi access points or switches in large-scale wireless deployments.

7. Virtualization & Cloud Infrastructure

   • Supports bandwidth-intensive virtual machines and cloud-hosted applications with minimal latency.

8. Surveillance Systems

   • Consolidates data streams from multiple high-resolution IP cameras and NVRs over 10G fiber connections.
