Vivotek 120W 48VDC Switching Power Supply

The Vivotek 120W 48VDC Switching Power Supply is a high-quality power supply designed for use with Vivotek network cameras and other security devices. It provides stable 48V DC output with a 120W power rating, ensuring reliable performance for surveillance systems and networked devices.

Specifications

• Model: Vivotek 120W 48VDC Switching Power Supply
• Power Output: 120W
• Output Voltage: 48V DC
• Output Current: 2.5A
• Input Voltage: 100-240V AC
• Input Frequency: 50-60Hz
• Efficiency: High efficiency, typically around 85%
• Form Factor: Compact, desktop style
• Cooling: Passive cooling (fanless design)
• Protections: Over-voltage, over-current, short-circuit, and over-temperature protection
• Certifications: CE, UL, RoHS
• Dimensions: Approx. 135mm x 85mm x 45mm (L x W x H)
• Weight: ~0.6 kg

Features

• Stable 48V Output: Provides reliable 48V DC power for devices such as network cameras, NVRs, and other surveillance equipment.
• Compact Design: Space-saving form factor, suitable for installation in tight spaces.
• Fanless Operation: Silent, efficient passive cooling for low noise levels.
• Safety Protections: Includes over-voltage, over-current, short-circuit, and over-temperature protections to ensure safe and secure operation.
• High Efficiency: Ensures minimal energy loss, with a high efficiency rating for reduced operational costs.

Applications

• Surveillance Systems: Perfect for powering Vivotek IP cameras, NVRs, and other networked surveillance devices.
• Networking Equipment: Suitable for powering other 48V devices that require reliable and stable power.

Key Notes

• Ensure that your device is compatible with 48V DC input to ensure proper operation.
• Ideal for use in surveillance environments where continuous power supply is critical.
