Acconet 1200VA/600W Offline UPS AC-UPS-1000

The Acconet 1200VA/600W Offline UPS | AC-UPS-1000 is a reliable uninterruptible power supply designed for small to medium office equipment and sensitive devices. It provides 600W of backup power with modified sine wave output and features overload, short-circuit, and surge protection. The UPS offers automatic voltage regulation (AVR) to stabilize output voltage and comes with a compact tower design, making it ideal for home offices or small businesses. It also includes battery overcharge protection, an audible alarm for faults, and easy maintenance with hot-swappable batteries.

1. Product Overview

• Model: Acconet 1200VA/600W Offline UPS
• Type: Offline Uninterruptible Power Supply (UPS)
• Application: Designed to provide backup power and protection against power outages for small to medium office equipment, computers, and networking devices
• Power Rating: 1200VA / 600W
• Usage: Ideal for home offices, small businesses, and sensitive electronic devices

2. Electrical Specifications

• Input Voltage: 110V to 290V AC (auto-adjustable)
• Output Voltage: 220V ± 10% AC
• Frequency: 50Hz ± 1Hz
• Power Capacity: 1200VA / 600W
• Output Waveform: Modified Sine Wave
• Battery Type: Sealed Lead Acid (SLA)
• Battery Voltage: 12V (typically two 12V batteries)
• Recharge Time: 4-6 hours to 90% capacity
• Battery Life: Approximately 3-5 years (depending on conditions)

3. Physical Characteristics

• Form Factor: Tower design, compact and easy to position
• Dimensions: 136 x 130 x 360 mm (5.35 x 5.12 x 14.17 inches)
• Weight: Approximately 7.5 kg (16.53 lbs)

4. Environmental Specifications

• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Humidity: 0% to 90% non-condensing
• Storage Temperature: -15°C to 45°C (5°F to 113°F)

5. Protection Features

• Overload Protection: Automatically shuts off if the load exceeds UPS capacity
• Battery Overcharge Protection: Prevents battery damage due to overcharging
• Short-Circuit Protection: Protects the UPS and connected devices from damage
• Surge Protection: Safeguards against voltage spikes or surges

6. Indicators and Alarms

• Indicators: LED indicators for power on, battery charging, and battery low status
• Alarms: Audible alarms for battery low, overload, and fault conditions

7. Compatibility

• Supported Devices: Computers, networking devices, office equipment, and other sensitive electronics
• Usage: Ideal for providing short-term backup power during power outages, preventing downtime and data loss

8. Additional Features

• Automatic Voltage Regulation (AVR): Provides stability and maintains output voltage despite input fluctuations
• Energy-efficient Design: Low standby power consumption
• Easy Maintenance: Hot-swappable battery design for easier battery replacement

9. Warranty and Support

• Warranty: 1-year limited warranty
• Support: Manufacturer provides technical support for troubleshooting and installation

10. Packaging

• In the Box:
  • 1 x Acconet 1200VA/600W Offline UPS
  • User manual
  • Power cord
  • Battery cables

Key Benefits:

• Reliable Power Backup: Provides 1200VA / 600W of backup power for critical devices during power outages
• Compact and Efficient: Ideal for small spaces and energy-efficient operation
• Built-in Protection: Features overload, short-circuit, and surge protection to safeguard connected devices
• Automatic Voltage Regulation (AVR): Ensures consistent voltage output to protect sensitive electronics from power fluctuations
