Ubiquiti UISP 60GHz/5GHz PtMP Wave Station

The Ubiquiti UISP Wave Station is a high-performance, dual-band Point-to-MultiPoint (PtMP) access point designed for modern wireless ISP deployments. Operating on both the 60GHz mmWave and 5GHz frequency bands, it delivers exceptional throughput and low latency over short to medium distances, ideal for dense urban and suburban environments. The 60GHz band enables multi-gigabit speeds with minimal interference, while the 5GHz backup ensures link reliability in adverse weather conditions. Engineered for seamless integration with the UISP ecosystem, the Wave Station supports centralized network management, remote monitoring, and scalable client connectivity. Its sleek, weather-resistant design ensures robust performance in outdoor installations, making it an essential solution for ISPs looking to expand high-speed wireless coverage efficiently.

Technical Specifications:

• Dimensions: Ø424.4 x 166.2 mm (Ø16.7 x 6.5″)

• Weight: Without mount: 2.59 kg (5.7 lb); With mount: 3.79 kg (8.4 lb)

• Enclosure Material: UV stabilized plastic

• Mount Material: Galvanized steel

• Pole Mount Diameter: 25 to 76.2 mm (1 to 3″)

• Wind Loading: 286 N at 200 km/h (64.3 lbf at 125 mph)

• Weatherproofing: IPX6

• Processor: Dual ARM Cortex-A53 cores at 1 GHz

• Memory: DDR3L 512 MB

• Networking Interface: (1) GbE RJ45 port

• Max. Power Consumption: 18W

• Power Method: 48V DC passive PoE 4-pairs (1, 2+, 3, 6-) (4, 5+, 7, 😎 or 2-pairs (4, 5+, 7, 😎

• Power Supply: 48V DC, 0.65A gigabit PoE adapter (included)

• GPS: Yes

• Button: Factory reset

• LEDs: Power, Ethernet, GPS, link

• Operating Temperature: -40 to 60° C (-40 to 140° F)

• Operating Humidity: 5 to 95% noncondensing

• Certifications: FCC, IC, CE

• Operating Frequency: 57 to 71 GHz (depends on regulatory region)

• Channel Bandwidth: 2160, 1080 MHz

• Operating Channels: 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz (depends on regulatory region)

• Total Throughput: 2 Gbps (1 Gbps duplex)

• Maximum Range: 8+ km

• Encryption: WPA2-PSK (AES)

• Operating Mode: PtMP station

• Ubiquiti Specific Features: Wave AI, discovery protocol

• Services: UISP, ping watchdog, NTP client, SNMP

• Tools: Antenna alignment, discovery utility, ping, trace route, speed test

• Network: Bridge/Router mode

• Software Management: Bluetooth management for easy setup over UISP app

• WEB UI: Minimum software requirements: Any modern web browser/iOS or Android based smartphone
