Ubiquiti UniFi Enterprise 8 Port 2.5Gbps PoE 120W Switch

The Ubiquiti UniFi Switch Enterprise 8 PoE (USW-Enterprise-8-PoE) is a compact, fully managed Layer 3 switch designed for small to medium-sized networks requiring high-speed connectivity and Power over Ethernet (PoE) capabilities. It features eight 2.5GbE RJ45 ports, each supporting IEEE 802.3at PoE+, and two 10G SFP+ ports for high-speed uplinks. With a total PoE power budget of 120W, it can power devices such as access points, cameras, and phones. The switch offers advanced Layer 3 features including static routing, DHCP, and VLAN support, and is integrated into the UniFi Network Controller for centralized management. Its 1.3″ LCM color touchscreen provides real-time system and connection insights, while the compact form factor ensures space-efficient deployment.

🔌 Ports & Connectivity

• 8 x 2.5GbE RJ45 Ports: Supports IEEE 802.3af/at PoE+ (Pins 1, 2+; 3, 6-)

• 2 x 10G SFP+ Ports: Supports 1/10 Gbps speeds

• Max. PoE+ Wattage per Port by PSE: 32W

• Total PoE Power Budget: 120W

• Voltage Range:

  • PoE Mode (802.3af): 44–57V

  • PoE+ Mode (802.3at): 50–57V

⚙️ Performance

• Total Non-Blocking Throughput: 40 Gbps

• Switching Capacity: 80 Gbps

• Forwarding Rate: 59.52 Mpps

• MAC Address Table Size: 16,000 entries

• Layer 3 Features:

  • DHCP Server (Local Networks)

  • Inter-VLAN Routing (Local Networks)

  • Static Routing (Local Networks)

• Layer 2 Features:

  • LACP Port Aggregation

  • STP & RSTP

  • IGMP Snooping

  • 802.1X Control

  • MAC-Based ACLs & Device Isolation

  • Storm Control

  • Port Mirroring

  • Jumbo Frames

  • LLDP-MED

  • Voice VLAN

  • Loop Protection

  • DHCP Snooping & Guarding

  • Egress Rate Limit

  • Flow Control

  • Multicast & Broadcast Rate Limiting

  • MAC Address Blocking

  • IP-Based ACLs & Network Isolation

  • MAC-Based Port Restriction

  • Port Isolation

⚡ Power & Management

• Max. Power Consumption:

  • Excluding PoE Output: 30W

  • Including PoE Output: 150W

• Power Input: 100–240V AC, 50/60 Hz, 2A Max

• Power Supply: AC/DC, internal, 150W

• Management Interface: Ethernet In-Band

• Display: 1.3″ LCM Color Touchscreen

• Mounting: Desktop-mountable (Do not physically stack the USW-Enterprise-8-PoE)

📦 Physical & Environmental

• Dimensions: 200 x 248 x 44 mm (7.9 x 9.8 x 1.7 inches)

• Weight: 2.4 kg (5.3 lb)

• Enclosure Material: Polycarbonate

• Operating Temperature: -5°C to 45°C (23°F to 113°F)

• Operating Humidity: 10% to 90% non-condensing

• Certifications: CE, FCC, IC

• ESD/EMP Protection:

  • Air: ±16 kV

  • Contact: ±12 kV

This USW-Enterprise-8-PoE switch is designed for high-performance networking environments, offering advanced Layer 3 features and seamless integration with the UniFi Network Controller for centralized management.
