Ubiquiti UniFi Switc Enterprise XG 24 10GbE RJ45

The Ubiquiti UniFi Switch Enterprise XG 24 is a high-performance, fully managed Layer 3 switch designed for enterprise and data center environments requiring robust 10GbE networking. Featuring 24 RJ45 ports supporting 10 Gigabit Ethernet, it provides ultra-fast connectivity for demanding workloads, large-scale data transfers, and high-density network aggregation. Built to integrate seamlessly with the UniFi Network platform, it offers centralized management, advanced traffic control, and monitoring through UniFi’s intuitive controller interface. With its durable, rack-mountable design and quiet, fanless cooling system, the Switch Enterprise XG 24 is ideal for deployments where high throughput and reliability are mission-critical.

🖥️ Hardware Specifications

• Total Non-Blocking Throughput: 290 Gbps

• Switching Capacity: 580 Gbps

• Forwarding Rate: 431.52 million packets per second (Mpps)

• Max. Power Consumption: 100W

• Power Supply: Internal AC/DC, 100W

• Power Input:

  • Universal AC input: 100–240V AC, 2A Max, 50/60 Hz

  • USP-RPS DC input: 11.5V DC, 8.7A

• Management Interface: Ethernet In-Band

• Enclosure Material: SGCC Steel

• Mounting Material: SGCC Steel

• ESD/EMP Protection:

  • Air: ±16 kV

  • Contact: ±12 kV

🔌 Networking Ports

• 24 x 10G RJ45 Ports: Auto-sensing 100/1000/2500/5000/10000 Mbps

• 2 x 25G SFP28 Ports: 1/10/25 Gbps

  • Note: SFP28 ports do not support mixed speeds at 25Gbps mode. Once one port is configured at 25Gbps, the others will be limited to 25Gbps as well. Mixed speeds are supported only when all ports are set to 1Gbps or 10Gbps.

📱 Display & Indicators

• Display: 1.3″ LCM Color Touchscreen

  • Displays bootup animation, firmware upgrade status, and adoption status (white for factory defaults, blue when adopted)

• Button: Factory Reset

• LED Indicators:

  • White: Link or Activity

  • Status: System

  • Ethernet: Link/Activity

🌡️ Environmental & Certifications

• Operating Temperature: -5°C to 40°C (23°F to 104°F)

• Operating Humidity: 10% to 95% non-condensing

• Certifications: CE, FCC, IC

📦 Dimensions & Weight

• Dimensions: 442 x 44 x 285 mm (17.4 x 1.7 x 11.2 inches)

• Weight:

  • Without Mount: 4.47 kg (9.85 lb)

  • With Mount: 4.57 kg (11.02 lb)
