Zebra ZC100 Single-Sided 300 x 300 DPI, PVC ID Card Printer

The Zebra ZC100 Single-Sided 300 x 300 DPI, PVC ID Card Printer  is a compact, single-sided ID card printer designed for easy, high-quality card printing. It delivers 300 x 300 DPI resolution, with print speeds of up to 150 color cards per hour and 700 monochrome cards per hour. With a 100-card input and output capacity, it’s perfect for small to medium card printing needs. The ZC100 offers USB 2.0 connectivity, with an optional Ethernet upgrade, and supports CR-80 and CR-79 card sizes.

Zebra ZC100 Single-Sided ID Card Printer Specifications

General Features:

• Model: Zebra ZC100 Single-Sided ID Card Printer
• Print Technology: Direct-to-card dye-sublimation and resin thermal transfer
• Print Capability: Single-sided (simplex)
• Resolution: 300 x 300 DPI (dots per inch)
• Print Speed:
  • Color printing: Up to 150 cards per hour (YMCKO)
  • Monochrome printing: Up to 700 cards per hour
• Card Thickness:
  • Minimum: 10 mil (0.25mm)
  • Maximum: 40 mil (1.02mm)
• Card Size Compatibility: CR-80 (85.6mm x 53.98mm) standard size, CR-79 adhesive-backed cards
• Card Material Supported: PVC, PVC composite, and laminated cards

Card Feeding and Output:

• Card Feeder Capacity: 100 cards (30 mil)
• Card Output Hopper Capacity: 100 cards (30 mil)
• Manual Feed Slot: Yes (for single card feed)

Connectivity:

• Standard Interface: USB 2.0
• Optional Interface: Ethernet (via ZC100 Ethernet upgrade kit)
• Operating System Compatibility:
  • Windows: 7, 8, 10
  • macOS: 10.9, 10.10, 10.11, 10.12, 10.13, 10.14
  • Linux (via Virtual COM port)

Physical and Environmental Specifications:

• Dimensions:
  • Height: 258mm (10.16 inches)
  • Width: 157mm (6.2 inches)
  • Depth: 383mm (15.1 inches)
• Weight: 3.9kg (8.6 lbs)
• Operating Temperature: 15°C to 30°C (59°F to 86°F)
• Operating Humidity: 20% to 80% non-condensing
• Storage Temperature: -40°C to 60°C (-40°F to 140°F)
• Storage Humidity: 10% to 90% non-condensing

Print Ribbon Options:

• Full-color ribbons: YMCKO, YMCKOK, Half-panel color ribbons
• Monochrome ribbons: Black, White, Gold, Silver, Red, Blue, Green
• Ribbon Capacity:
  • YMCKO: 200 prints per roll
  • Monochrome: 2000 prints per roll

Security Features:

• Printer Security: Kensington® lock slot for physical security
• Data Encryption: AES-256 Encryption for secure card data transfer

Power Requirements:

• Power Supply: 100-240VAC, 50-60Hz
• Power Consumption:
  • Standby: 5 watts
  • Printing: 60 watts

Certifications and Compliance:

• Safety: UL, CE, FCC, CCC, BIS
• Environmental: ENERGY STAR® qualified,
