Ubiquiti UniFi Pro Max Etherlighting 48 Port

The Ubiquiti UniFi Pro Max 48-Port PoE Switch (USW-Pro-Max-48-PoE) is a high-performance Layer 3 managed switch designed to meet the demands of modern enterprise networks. It features 48 ports in total, including 32 Gigabit Ethernet (GbE) ports and 16 2.5 GbE ports, with a total Power over Ethernet (PoE) budget of 720W, enabling it to power a wide range of devices such as access points, IP cameras, and VoIP phones. The switch supports PoE++, providing up to 60W per port, ensuring compatibility with high-powered devices.

Equipped with four 10G SFP+ ports, the USW-Pro-Max-48-PoE facilitates high-speed uplinks and backbone connectivity. Its Etherlighting™ technology enhances visibility by illuminating ports to indicate location, speed/link status, and native VLAN/network, simplifying network management and troubleshooting. The switch is managed via the UniFi Network Controller, offering centralized control and monitoring. With a rugged SGCC steel enclosure and a 1.3-inch touchscreen display, it is built for durability and ease of use. The USW-Pro-Max-48-PoE is ideal for large-scale deployments requiring robust performance and advanced features.

🔧 Technical Specifications

Physical & Mechanical:

• Dimensions: 442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7″)

• Weight: 6.2 kg (13.7 lb) without mounting brackets; 6.3 kg (13.9 lb) with mounting brackets

• Enclosure Material: SGCC steel

• Mounting: Rack-mountable (1U)

Networking:

• Ports:

  • 32 x Gigabit Ethernet (GbE) RJ45 ports

  • 16 x 1/2.5 GbE RJ45 ports

  • 4 x 10G SFP+ ports

• Total Non-Blocking Throughput: 112 Gbps

• Switching Capacity: 224 Gbps

• Forwarding Rate: 166.656 million packets per second (Mpps)

• MAC Address Table Size: 32,000 entries

• Layer 3 Table Size:

  • ARP Entries: 12,000

  • IPv4 Routes: 12,000

• Supported VLANs: 1,000

Power:

• Power Supply: Internal AC/DC, 820W

• Power Input: Universal input, 100–240V AC, 50/60 Hz

• Power Consumption:

  • Max. Power Consumption (excluding PoE output): 100W

  • Total Available PoE: 720W

• PoE Output:

  • PoE Ports: 32 ports (PoE/PoE+)

  • PoE++ Ports: 16 ports (60W)

  • Max. PoE Wattage per Port by PSE:

    • PoE: 15.4W

    • PoE+: 30W

    • PoE++: 60W

  • Voltage Range PoE Mode:

    • PoE: 44–57V

    • PoE+: 50–57V

Management & Software:

• Management Interface: Ethernet In-Band

• Application Requirements: UniFi Network Version 8.0.24 and later

Environmental:

• Operating Temperature: -5 to 40°C (23 to 104°F)

•  Humidity: 10 to 90% non-condensing

• Certifications: CE, FCC, IC

Display & Controls:

• LCD Display: 1.3″ touchscreen

• Button: Factory reset

Switching Features:

• Layer 2 Features:

  • IGMP snooping

  • STP / RSTP with priorities and port-level disable

  • Port isolation

  • Storm control

  • Voice VLAN

  • Port mirroring

  • LACP port aggregation

  • Multicast / broadcast rate limiting

  • MAC address blocking

  • Flow control

  • 802.1X control

  • Jumbo frames

  • Proprietary loop protection

  • DHCP snooping / guarding

  • Egress rate limit

  • LLDP-MED

  • Port restricted by MAC

  • Device isolation with ACLs

• Layer 3 Features:

  • DHCP for locally-managed networks

  •  relay

  • Inter-VLAN routing between networks on same switch

  • Static routing between local networks

  • Network isolation with ACL

Etherlighting™:

• Ethernet Ports: Indicates port location, speed/link, and native VLAN/network

• SFP+ Ports: Indicates port location, speed/link, and native VLAN/network
