Ubiquiti UniFi Protect G4 WiFi Video Doorbell

The Ubiquiti UniFi Protect G4 WiFi Video Doorbell (UVC-G4-Doorbell) is a high-definition, smart video doorbell designed for seamless integration with the UniFi Protect ecosystem. It features a 5MP CMOS sensor capable of streaming 1600×1200 (2MP) HD video at 30 frames per second, ensuring clear and detailed video feeds. The built-in infrared (IR) LED illumination and IR cut filter provide enhanced night vision, allowing for reliable monitoring even in low-light conditions. Equipped with a passive infrared (PIR) motion detection sensor, the G4 Doorbell can detect movement around your entrance and send instant alerts, enhancing security by notifying you of potential visitors or intruders.

The device also supports real-time two-way audio communication with echo cancellation, enabling clear conversations with visitors through the UniFi Protect mobile app or web interface. Designed for durability, the G4 Doorbell boasts an IPX4-rated weather-resistant enclosure, making it suitable for outdoor installations in various environmental conditions. The built-in display allows for customizable messages and system information, providing an interactive experience for visitors. Dual-band 802.11ac Wi-Fi connectivity ensures stable and fast connections, facilitating smooth video streaming and communication.

📷 Camera & Optics

• Sensor: 5MP CMOS sensor

• Lens: Fixed focal length

• Field of View:

  • Main Camera: Horizontal: 138°, Vertical: 114°, Diagonal: 155°

  • Package Camera: Horizontal: 97.5°, Vertical: 79.4°, Diagonal: 118.2°

• Resolution: 1600 x 1200 (4:3 aspect ratio)

• Frame Rate: Up to 30 FPS

• Night Vision: Built-in IR LED illumination with IR cut filter

• Video Compression: H.264

🔧 Hardware & Power

• Processor: Quad-core ARM Cortex-A53

• Memory: 512 MB RAM

• Storage: 256 MB flash memory

• Power Consumption: Max 10W

• Supported Voltage Range: 37–57V DC

• Power Methods:

  • 16–24V AC, 1.25A Max, 50/60 Hz

  • USB-C 5V DC, 2A

• Networking Interface: 802.11a/b/g/n/ac WiFi, Bluetooth 5.0

• Ethernet Support: Gigabit Ethernet via optional UACC-Adapter-DBPOE

• Mounting Options: Flat wall mount (included), 20° wedge mount (included)

• Enclosure Material: Polycarbonate, aluminum alloy

• Mounting Material:

  • Flat wall mount: aluminum alloy

  • 20° wedge mount: polycarbonate

• Weatherproofing: IPX4 rated

• Operating Temperature: -10 to 40°C (14 to 104°F)

• Operating Humidity: 10 to 90% non-condensing

• Certifications: CE, FCC, IC

🔊 Audio & Smart Features

• Audio:

  • Microphone: Yes (can be disabled in software)

  • Speaker: Yes

• Two-Way Audio: Real-time communication with echo cancellation

• Motion Detection: Passive Infrared (PIR) sensor

• Smart Detection: People, vehicles, and animal detection

📱 Software & Integration

• Management Interface: UniFi Protect application

• Mobile App Support: UniFi Protect for iOS and Android

• Compatible Chimes: Supports various mechanical and digital chimes from manufacturers like Broan-NuTone, Heath Zenith, Craftmade, and Newhouse Hardware
