Ubiquiti UniFi Protect G5 Flex 4MP IP Camera

The Ubiquiti UniFi Protect G5 Flex (UVC-G5-Flex) is a compact, high-performance 4MP IP camera designed for both indoor and outdoor surveillance. It captures 2688 x 1512 resolution video at 30 frames per second, providing clear and detailed imagery. The camera features a 102.4° horizontal field of view and integrated IR LEDs with an IR cut filter, enabling night vision up to 6 meters (20 feet). Audio capabilities include a built-in microphone that can be disabled via software.

With Power over Ethernet (PoE) support, it simplifies installation by requiring only a single cable for both power and data. The G5 Flex is housed in a weather-resistant IPX4-rated enclosure and offers IK04-rated tamper resistance, ensuring durability in various environments. It supports smart detection features for people, vehicles, and animals when used with UniFi Protect software. Multiple mounting options are included, and the camera is compatible with UniFi Protect for centralized management

📐 Mechanical Specifications

• Dimensions: Ø48 x 107.5 mm (Ø1.9 x 4.2″)

• Weight: 170 g (6 oz)

• Enclosure Material: Polycarbonate

• Mounting Material: Polycarbonate

• Weatherproofing: IPX4 (suitable for covered outdoor use)

• Impact Resistance: IK04

🔍 Optics & Imaging

• Sensor: 5MP CMOS sensor

• Lens: Fixed focal length

• Field of View:

  • Horizontal: 102.4°

  • Vertical: 54.9°

  • Diagonal: 120.6°

• Resolution: 4MP (2688 x 1512) at 16:9 aspect ratio

• Maximum Frame Rate: 30 FPS

• Night Mode: Built-in IR LED illumination with IR cut filter

• Night Vision Range: Up to 6 meters (20 feet)

⚙️ System & Networking

• Processor: Dual-core ARM Cortex-A7

• Networking Interface: 10/100 Mbps RJ45 Ethernet port

• Power Consumption: Maximum 4W

• Power Method: Power over Ethernet (PoE)

• Supported Voltage Range: 37–57V DC

• LED Indicators: Red, Green, Blue, White

• Reset Button: Factory reset

🔊 Audio

• Microphone: Integrated microphone (can be disabled)

🛠️ Mounting & Installation

• Included Mounting Options:

  • Desktop

  • Wall

  • Pole

  • Hard-ceiling

• Optional Mounts:

  • Ceiling

  • Conduit

• Pole Mount Diameter: 1–1.5″ (25–38 mm)

🌡️ Environmental & Compliance

• Operating Temperature: -20°C to 40°C (-4°F to 104°F)

• Operating Humidity: 0 to 90% non-condensing

• Certifications: CE, FCC, IC

📱 Software Compatibility

• UniFi Protect Web Application: Version 2.2.7 or later

• UniFi Protect Mobile App: iOS and Android version 1.10.0 or later
