Ubiquiti UniFi WiFi 7 Tri-Band Pro In-Wall AP

The Ubiquiti UniFi Wi-Fi 7 Tri-Band Pro In-Wall Access Point is a sleek, high-performance device designed to deliver ultra-fast, reliable Wi-Fi coverage in compact, in-wall form factor. Ideal for providing enterprise-grade Wi-Fi in environments where space is limited, such as offices, hotels, and apartments, it supports the latest Wi-Fi 7 (802.11be) standard. With tri-band capabilities, high throughput, and seamless management through the UniFi Network Controller, this AP is perfect for dense environments with high demand for wireless connectivity.

Specifications

• Wi-Fi Standard: Wi-Fi 7 (802.11be)
• Frequency Bands: Tri-band (2.4 GHz, 5 GHz, 6 GHz)
  • 2.4 GHz: 2×2 MIMO
  • 5 GHz: 4×4 MIMO
  • 6 GHz: 4×4 MIMO

• Max Wireless Speed:

  • 2.4 GHz: Up to 1.5 Gbps
  • 5 GHz: Up to 4.8 Gbps
  • 6 GHz: Up to 6.4 Gbps
  • Total Combined Speed: Up to 12.7 Gbps
• MIMO: 8×8 MU-MIMO (Multi-User, Multiple Input, Multiple Output)

• Ports:

  • 1x Gigabit Ethernet (PoE in)
  • 1x 10G SFP+ port (for high-speed uplinks)

• Power Supply:

  • PoE (802.3at/PoE+), max 35W

• Antenna:

  • 4 external, high-gain omnidirectional antennas

• Mounting:

  • In-wall mountable (standard electrical box)

• Weather Resistance:

  • IP54 rated (dust and water-resistant for indoor use)

• Management:

  • Managed via UniFi Network Controller (cloud and on-premises options)

• Security:

  • WPA3 encryption
  • Enterprise-level security features

• Dimensions:

  • Height: 7.9 inches (200 mm)
  • Width: 5.5 inches (140 mm)
  • Depth: 1.1 inches (28 mm)

• Weight:

  • 0.7 kg (1.5 lbs)

• Power Consumption:

  • Typical: ~25W (depending on usage)

• Max Concurrent Clients:

  • Designed to support high numbers of devices, ideal for enterprise and public spaces with many connected users.

• Other Features:

  • Seamless roaming for mobile devices
  • Mesh networking support for expanded coverage
  • Advanced RF management and automatic channel selection
  • Advanced QoS (Quality of Service) for traffic optimization

• Applications

  1. Office and Corporate Environments

     • Provides fast, secure Wi-Fi in office spaces, ensuring seamless connectivity for employees and visitors in meeting rooms, workstations, and common areas.

  2. Multi-Dwelling Units (MDUs)

     • Ideal for apartments, condos, or residential complexes where discreet in-wall solutions are needed for uniform coverage across multiple rooms.

  3. Hospitality and Hotels

     • Perfect for guest rooms, lobbies, and common areas, offering high-speed internet and reliable connections for guests and staff.

  4. Retail and Customer-Facing Spaces

     • Provides strong Wi-Fi coverage in retail stores, cafes, and restaurants, ensuring both customers and staff have reliable access to the network.
  5. High-Density Public Spaces
     • Suitable for use in public areas like libraries, airports, and conference centers where multiple devices require uninterrupted Wi-Fi connectivity.

  6. Smart Home Networks

     • Ideal for home installations where discreet, high-performance wireless coverage is needed for IoT devices, smart home systems, and media streaming.

  7. Educational Institutions

     • Can be deployed in classrooms, dormitories, and campus buildings to support both student and staff connectivity.

  8. Healthcare Facilities

     • Perfect for hospitals, clinics, and care homes where secure, high-speed internet access is required for both staff operations and patient care systems.
