VENUS 3400VA Online UPS with LCD and Battery Backup

The UPS – VENUS 3400VA (2400W) – Online is a robust and high-capacity uninterruptible power supply designed to deliver continuous, clean, and reliable power for critical systems and sensitive electronics. With an output of 3400VA (2400W) and true online double-conversion technology, it ensures complete isolation from power disturbances such as surges, spikes, and outages. Ideal for use in data centers, medical equipment, industrial automation, and high-performance workstations, this UPS offers features such as a pure sine wave output, LCD display for real-time monitoring, extended runtime support, and intelligent battery management. Its generator compatibility, advanced protection features, and smart communication interfaces make the VENUS 3400VA an essential solution for uninterrupted power and maximum uptime.

Specifications

• Capacity: 3400VA / 2400W

• Topology: Online Double-Conversion (Pure Sine Wave)

• Input Voltage Range: 165–275 VAC

• Frequency: 45–65Hz

• Output Voltage: 230V ±2% (Battery Mode)

• Waveform: Pure Sine Wave, THD <3% at linear load

• Overload Capability: 110% for 30 seconds; 120% for 2 seconds

• Battery Type: 48VDC Lead-Acid Maintenance-Free

• Recharge Time: 90% in 9 hours

• Charging Voltage: 55VDC ±1%

• Backup Time: Depends on external battery capacity

• LCD Display: Real-time status and diagnostics

• Communication Ports: RS232 / RS485; SNMP optional

• Adjustable Charger: 1–20 Amps for extended battery options

• Cold Start Function: Yes

• Generator Compatibility: Yes

• Battery Options: Supports internal or external batteries

• Protection Features:

  • Overload Protection

  • Short Circuit Protection

  • Input High/Low Voltage Protection

  • Battery High/Low Voltage Protection

  • Battery Anti-Polarity Protection

  • High Temperature Protection

• Audible Alarms: Mains failure, battery low voltage, overload

• Physical Dimensions: 475 x 225 x 330 mm

• Net Weight: 21 kg

• Operating Temperature: 0–40°C

• Humidity: 10–90% (non-condensing)

• Noise Level: <38dB at 1 meter

• Software Compatibility: Supports Windows, Linux, Unix, and Mac

Applications

1. Data Centers & Server Rooms

   • Ensures uninterrupted operation of servers, storage systems, and networking hardware.

2. Medical & Laboratory Equipment

   • Provides stable and clean power for sensitive devices like diagnostic machines and lab instruments.

3. Industrial Automation

   • Powers programmable logic controllers (PLCs), motor drives, and control panels in manufacturing lines.

4. Telecommunication Systems

   • Protects critical telecom infrastructure such as PBX systems, routers, and switches.

5. Banking & ATM Operations

   • Ensures uptime for ATMs, banking terminals, and transaction servers.

6. Security & Surveillance Systems

   • Maintains power to CCTV, access control, alarm systems, and NVRs without interruption.

7. Retail & Point-of-Sale (POS) Systems

   • Prevents data loss and transaction errors in retail billing systems and kiosks.

8. Home & Small Office IT Environments

   • Supports PCs, NAS devices, routers, and modems for remote work or home networks.

9. Educational Institutions & E-Learning Labs

   • Keeps digital classrooms, servers, and e-learning platforms running smoothly.

The VENUS 3400VA Online UPS is suitable for a wide range of applications, including commercial, industrial, security, home, and IT environments. Its robust design and advanced features ensure reliable power protection for critical equipment.
